1

Interface

• 1 RJ-11 VDSL2/ADSL2+ port
• 1 10/100/1000Mbps RJ-45 WAN/LAN Port
• 3 10/100/1000Mbps RJ-45 LAN ports
• 1 USB 2.0 port

2

WIFI

• Frequency: 2.4 GHz, 5GHz
• Max EIRP: 20 dBm (100mw) @ 2.4GHz, 23 dBm (200mw) @ 5GHz
• IEEE 802.11a/n/ac Wi-Fi @ 5GHz(2x2)
• IEEE 802.11b/g/n Wi-Fi @ 2.4GHz(2x2)
• WEP/WPA/WPA2 Security
• Up to four broadcast/hidden SSIDs on each band

3

Buttons

• Power ON/OFF
• WPS
• Reset
• Wi-Fi Radio

4

LEDs

• Power, Broadband, Internet, 2.4G, 5G, WPS, USB

5

VDSL Standards

• G.993.2 VDSL2 (Up to 35b profile)
• G.993.5 (G.vectoring) compliance, G.998.4 (G.INP) compliance
• Bandplan: Annex A/B
• Dual latency
• UPBO/DPBO
• Double-end line test(DELT)
• RFI Notching
• Bit Swap

6

Networking

• IPv4/IPv6 Dual Stack
• NAT/PAT/ALG
• Port mapping/DMZ/Virtual server
• UPnP IGD with NAT traversal capability
• Static routing/dynamic routing
• Dynamic DNS relay
• DHCP client/server
• IGMP and MLD snooping/proxy

7

Security

• Stateful Packet Inspection (SPI)
• Denial of Service (DoS) prevention
• Multiple VPN (IPSec, PPTP,L2TP) passthrough
• MAC/IP/URL filtering
• Black and white list

8

Management

• TR-069 remote management
• Web GUI management
• Local built-in diagnostic function
• Logs and statistics
• Remote upgrade by HTTP

9

Electrical Characteristics

• AC adapter: 12V DC, 1A
• Power consumption: 8.3 Watts

10

Physical Characteristics

• Net weight: 350 g
• Dimensions: 221x186x89 mm

11

Environmental Characteristics

• Operating temperature: 0 °C~ 40°C (32°F ~ 104°F)
• Humidity: 5% ~ 95% (non-condensing)
